Nizar Sheetsandplates, located in Amman, Jordan, has built a solid reputation as a reliable manufacturer and supplier of top-notch Stainless Steel 347H sheets and plates. Known for their meticulous engineering and rigorous quality checks, Nizar Sheetsandplates provides products that align with international standards, serving a wide range of industrial needs. With years of expertise in the metal sector, the company guarantees consistent performance, durability, and reliability in every sheet and plate they produce. Their stainless steel offerings are crafted to endure extreme conditions, making them perfect for critical applications where strength, resistance to corrosion, and thermal stability are essential.
The Stainless Steel 347H sheets and plates are mainly made up of iron, chromium (17–19%), nickel (9–13%), and a touch of niobium or tantalum, which helps stabilize the structure and prevents carbide precipitation. The “H” designation signifies a higher carbon content (0.04–0.10%), which boosts high-temperature strength. These sheets and plates boast impressive mechanical properties, including a tensile strength of around 515–620 MPa, yield strength of 205–275 MPa, and an elongation of 40% over 50 mm. They provide exceptional creep resistance, good toughness, and remarkable corrosion resistance in oxidizing environments, making them ideal for demanding industrial applications.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 347H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 4(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 347H | 1.4961 | S34709 | SUS 347H | X12CrNiTi18-9 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 347H sheets and plates find extensive use in industries that require high strength and corrosion resistance at elevated temperatures. They’re commonly utilized in aerospace components, chemical processing equipment, heat exchangers, boilers, and superheaters. Furthermore, they are employed in petrochemical plants, power generation units, and marine applications due to their ability to resist stress corrosion cracking and maintain structural integrity under extreme conditions. Their versatility, durability, and reliability make them a go-to choice for engineers and designers tackling projects that demand long-term performance and resilience against harsh environments.
Stainless steel 347H sheets and plates are widely used in applications requiring high temperature resistance and excellent corrosion protection. Typical applications are petrochemical industry components, such as reactors and heat exchangers, as well as parts for power plants, including turbine and boiler parts Its ability to withstand harsh conditions is provided suitable for aerospace, cryogenic and chemical process industries. Additionally, 347H is used in kitchen appliances, air filters and welded structures, providing durability and resistance to scaling and oxidation in high-temperature environments.
