From the heart of Amman, Jordan, Nizar Sheetsandplates has built a strong reputation as a reliable source for quality steel products. We take pride in our deep understanding of the regional market’s needs, particularly when it comes to versatile materials like our Stainless Steel 201 Angle. This specific grade offers an excellent balance of performance and affordability, making it a go-to choice for a wide array of projects across the construction and manufacturing sectors, backed by our commitment to consistent quality and dependable service.
The composition of Stainless Steel 201 is engineered for resilience, primarily blending chromium, nickel, and manganese. This combination gives the angle its notable strength and good corrosion resistance, making it a durable choice for many demanding environments. In terms of mechanical properties, it boasts a commendable tensile strength and yield strength, allowing it to withstand significant structural loads and stress. This robustness, coupled with its inherent ductility, means it can be fabricated and welded with relative ease to meet specific project requirements.
| Specifications | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 201 Angle | 5mm to 9mm |
| Thickness | 3.0mm – 120mm |
| Length | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | C | Mn | Si | P | S | Cr | Ni | N |
| SS 201 | 0.15 max | 5.5 – 7.5 | 100 max | 0.06 max | 0.03 max | 16.00-18.00 | 0.3 – 0.5 | – |
| Temper | Tensile Strength | Yield Strength | Elongation | Rockwell | ||
|---|---|---|---|---|---|---|
| KSi | MPa | KSi | MPa | in 2 inches % | ||
| 1/2 Hard | 150 | -1034 | 110 | -758 | 10 | C-32 |
| 1/4 Hard | 125 | -862 | 75 | -517 | 20 | C-25 |
| 3/4 Hard | 175 | -1207 | 135 | -931 | 7 | C-37 |
| Annealed | 95 | -655 | 45 | -310 | 40 | B-90 max. |
| Full Hard | 185 | -1276 | 140 | -965 | 5 | C-41 |
| STANDARD | UNS | WERKSTOFF NR. |
| SS 201 | S20100 | 1.4372 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 201 Angle provides excellent corrosion resistance, making it ideal for use in light to medium environments. Lightweight yet durable, it provides high stability and system integrity. Its excellent weldability and formability make it easy to manufacture in a variety of configurations. It has excellent oxidation resistance and works well at high temperatures. Affordable compared to other stainless steel grades, it maintains an attractive look with minimal maintenance. Its versatility allows it to be used in construction, automotive, and industrial applications, providing longevity and value.
| Width (mm) | Thickness (mm) | Width (Inches) | Thickness (Inches) |
|---|---|---|---|
| 20 x 20 | 3 to 5 | 3/4″ | 1/8 to 1/4 |
| 25 x 25 | 3 to 5 | 1″ | 1/8 to 1/4 |
| 30 x 30 | 3 to 5 | 1.1/8 | 1/8 to 1/4 |
| 32 x 32 | 3 to 6 | 1.1/4 | 1/8 to 1/4 |
| 35 x 35 | 3 to 6 | 1.3/8 | 1/8 to 1/4 |
| 38 x 38 | 3 to 6 | 1.1/2 | 1/8 to 1/4 |
| 40 x 40 | 3 to 6 | 1.5/8 | 1/8 to 1/4 |
| 45 x 45 | 3 to 6 | 1.3/4 | 1/8 to 1/4 |
| 50 x 50 | 3 to 6 | 2″ | 1/8 to 1/4 |
| 60 x 60 | 5 to 6 | 2.3/8 | 3/16 to 1/4 |
| 65 x 65 | 5 to 6 | 2.1/2 | 3/16 to 1/4 |
| 70 x 70 | 5 to 6 | 2.3/4 | 3/16 to 1/4 |
| 75 x 75 | 5 to 6 | 3″ | 3/16 to 1/4 |
The uses for this angle are incredibly diverse, forming the essential skeleton for everything from sturdy warehouse shelving and functional industrial frames to decorative architectural features. Its strength and corrosion resistance make it ideal for constructing storage racks, equipment supports, and even frames for windows and doors. Beyond heavy industry, you’ll find it adding clean, modern lines to handrails, furniture, and display units, proving that practicality and aesthetic appeal can go hand-in-hand, all while offering a cost-effective solution for builders and fabricators.
