Nizar Sheetsandplates, located in Amman, Jordan, specializes in providing top-notch quenched and tempered carbon steel sheets and plates. These products are celebrated for their outstanding strength, toughness, and reliability, making them perfect for demanding industrial and structural applications. Each sheet and plate is crafted under rigorous quality control measures, ensuring they meet international standards and deliver durable solutions for heavy-duty construction, machinery, and engineering projects. With a variety of thicknesses and dimensions available, Nizar Sheetsandplates guarantees that every quenched and tempered carbon steel product offers consistent mechanical performance and structural integrity, making them ideal for situations that require maximum strength and long-lasting durability.
The process of creating quenched and tempered carbon steel involves a heat treatment method that includes rapid cooling (quenching) followed by controlled reheating (tempering). This process enhances the steel’s hardness, tensile strength, and toughness while minimizing brittleness. The chemical makeup of this steel primarily consists of iron, with carefully controlled amounts of carbon, manganese, phosphorus, sulfur, and sometimes additional alloying elements, depending on the specific grade. As a result, this steel showcases impressive mechanical properties, such as high yield and tensile strength, excellent impact resistance, and good fatigue performance. It also boasts superior weldability and formability compared to other high-strength steels.
| tandard | ASTM A514 and A514M-13 |
| Grade | Grade 400, 80 and 500, WELTEN 140 KSI ,780E, 130 KSI , A514, S890Q, A710, TMCP 100 KSI, RQT 701, S690QL, S690QL1, S890QL1,S690Q, S890QL, Weldox 700, S960QL |
| Thickness: | 3 mm to 300 mm |
| Width: | 3000 mm, 2500 mm, 2000 mm, |
| Length: | Up to 12000 mm long |
| Delivery State | Quenched and Tempered |
| A514 Gr B | A514 Gr A | A514 Gr E | A514 Gr C | A514 Gr Q | A514 Gr H | A514 Gr S | A514 Gr M | A514 Gr F | A514 Gr K | A514 Gr J | A514 Gr R | A514 Gr P | A514 Gr T | |
| C | 0.012-0.021 | 0.015-0.021 | 0.012-0.020 | 0.010-0.020 | 0.014-0.021 | 0.012-0.021 | 0.011-0.021 | 0.012-0.021 | 0.010-0.020 | 0.010-0.020 | 0.012-0.021 | 0.015-0.020 | 0.012-0.021 | 0.008-0.014 |
| M | 0.070-1.000 | 0.080-1.010 | 0.040-0.070 | 1.010-1.050 | 0.095-1.030 | 0.095-1.030 | 1.010-1.050 | 0.045-0.070 | 0.060-1.000 | 1.010-1.050 | 0.045-0.070 | 0.085-1.015 | 0.045-0.070 | 1.020-1.050 |
| P | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 |
| S | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0035 | 0.0010 |
| Si | 0.020-0.035 | 0.040-0.080 | 0.020-0.040 | 0.015-0.030 | 0.015-0.035 | 0.020-0.035 | 0.015-0.045 | 0.020-0.035 | 0.015-0.035 | 0.015 | 0.020-0.035 | 0.020-0.035 | 0.020-0.035 | 0.040-0.060 |
| Ni | – | – | – | – | 1.020-1.050 | 0.030-0.070 | – | 1.020-1.050 | 0.070-1.000 | – | – | 0.090-1.010 | 1.020-1.050 | – |
| Cr | 0.040-0.065 | 0.050-0.080 | 1.040-2.000 | – | 1.000-1.050 | 0.040-0.065 | – | – | 0.040-0.065 | – | – | 0.035-0.065 | 0.085-1.020 | – |
| Mo | 0.015-0.025 | 0.018-0.028 | 0.040-0.060 | 0.015-0.030 | 0.045-0.060 | 0.020-0.030 | 0.010-0.060 | 0.045-0.060 | 0.040-0.060 | 0.045-0.060 | 0.050-0.065 | 0.015-0.025 | 0.045-0.060 | 0.045-0.060 |
| V | 0.003-0.008 | – | – | – | 0.003-0.008 | 0.003-0.008 | 0.006 | – | 0.003-0.008 | – | – | 0.003-0.008 | – | 0.003-0.008 |
| Ti | 0.001-0.003 | – | 0.001-0.010 | – | – | – | – | – | – | – | – | – | – | – |
| Z | 0.005-0.015 | – | – | – | – | – | – | – | – | – | – | – | – | |
| Cu | – | – | 0.015-0.050 | – | – | – | – | – | 0.015-0.050 | – | – | – | – | – |
| B | 0.0001-0.0005 | 0.00025 | 0.0001-0.0005 | 0.0001-0.0005 | – | 0.0001-0.0005 | 0.0001-0.0005 | 0.0001-0.0005 | 0.0001-0.0005 | 0.0001-0.0005 | 0.0001-0.0005 | – | 0.0001-0.0005 | 0.0001-0.0005 |
| Nb | – | – | – | – | – | – | 0.006 | – | – | – | – | – | – | – |
Grade | A514 Mechanical Property | |||
Tensile | Yield | Elongation | Thickness | |
A514 | Mpa | Min Mpa | Min % | mm |
760-895 | 690 | 18 | 20 | |
760-895 | 690 | 18 | 20-65 | |
690-895 | 620 | 18 | 65-150 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nizar Sheets and Plates based in Amman, Jordan, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
| Standard | Grade | Minimum Thickness (mm) | Maximum Thickness (mm) |
| Dillinger | Dillimax 890 T | 6 | 100 |
| Dillinger | Dillimax 965 T | 6 | 100 |
| EN10025 – 6 | S690QL | 6 | 200 |
| Dillinger | Dillimax 690T | 6 | 200 |
| EN10025 – 6 | S690QL1 | 6 | 150 |
| Dillinger | Dillimax 690 E | 6 | 150 |
| EN10025 – 6 | S890QL | 6 | 100 |
| Dillinger | Dillimax 1100 | 6 | 40 |
| THICKNESS | GRADE | LENGTH | WIDTH |
| 3/16 – 1 1/4 inch | GRADE B | UP TO 480 inch | 48″ – 120″ |
| INQUIRE | GRADE P | INQUIRE | INQUIRE |
| 3/16 – 2 1/2 inch | GRADE S | UP TO 480 inch | 48″ – 120″ |
| 3/16 – 2 inch | GRADE H | UP TO 480 inch | 48″ – 120″ |
| 3/16– 8 inch | GRADE Q | UP TO 480 inch | 48″ – 120″ |
| 3/16 – 2 1/2 inch | GRADE F | UP TO 480 inch | 48″ – 120″ |
| INQUIRE | GRADE A | INQUIRE | INQUIRE |
| 3/16 – 6 inch | GRADE E | UP TO 480 inch | 48″ – 120″ |
Quenched and Tempered Carbon Steel Sheet and Plate have several advantages, including superior strength and hardness, making them ideal for high-pressure applications Their high corrosion resistance ensures long-term performance in harsh environments. The tempering process improves hardness and reduces brittleness, resulting in better impact resistance and ductility. These materials also provide excellent machining, making them easier to cut, weld and fabricate. Furthermore, their cost-effectiveness, combined with superior performance makes quenched and tempered carbon steel sheets and plates desirable for industries such as manufacturing, automotive and heavy machinery
Yes, we offer custom sizes for Quenched and Tempered Carbon Steel Sheet and Plate to meet specific project needs. Our team at Nizar Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
These sheets and plates find extensive use in heavy engineering, structural components, pressure vessels, automotive parts, machinery, offshore structures, and fabrication projects where high strength, toughness, and reliability are essential. They are also utilized in applications that demand resistance to wear, fatigue, and high-impact loads. Nizar Sheetsandplates provides quenched and tempered carbon steel sheets and plates in precise dimensions and thicknesses, ensuring consistent quality throughout.
