Nestled in the industrial heart of Amman, Jordan, Nizar Sheetsandplates has built a strong reputation for supplying high-quality marine and industrial materials. We take particular pride in our inventory of Copper Nickel 7030 Channel, a product known for its exceptional durability in demanding environments. Sourced to meet the highest standards, this channel is a go-to solution for engineers and project managers who require reliability and long-term performance, especially where saltwater corrosion is a constant challenge. It represents our commitment to providing robust solutions that stand the test of time.
The strength of Copper Nickel 7030 lies in its unique composition, primarily a blend of 70% copper and 30% nickel, enhanced with small but crucial additions of iron and manganese. This specific alloying recipe grants it outstanding mechanical properties, including excellent tensile strength and impressive resistance to corrosion and erosion. It performs superbly in seawater, resisting biofouling and maintaining its integrity under high stress and flow rates. This combination makes it not just strong, but remarkably resilient against the harsh conditions it’s designed to face.
| Specifications | : | ASTM B151 / ASME SB151 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Cu-Ni 70/30 Angle | : | 5mm to 9mm |
| Cu-Ni 70/30 Channel | : | 40mm*20mm~300mm*300mm |
| Cu-Ni 70/30 Beam | : | 3″ thru 12.31″ |
| Cu-Ni 70/30 Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cu-Ni 70/30 | 65 min | 1.0 max | 0.05 max | 29-33 max | 0.4-1.0 max | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Cupro Nickel 70/30 | 2.0882 | C71500 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Copper Nickel 70/30 Channel offer several advantages. They are insoluble, especially in ambient seawater, making them ideal for marine applications. The alloy also provides excellent resistance to biofouling, providing durability under extreme conditions. Its strength and compression durability make it suitable for high-pressure environments. In addition, CuNi 70/30 has excellent thermal conductivity and is easy to weld, providing versatility in manufacturing. Its low maintenance requirements and high resistance to scaling and pitting further enhance its industrial appeal.
The primary use for this channel is within the marine industry, where it serves as a fundamental component for shipbuilding, offshore platforms, and desalination plant construction. Its corrosion-resistant nature makes it ideal for fabricating sturdy frames, supports, and structural elements that are constantly exposed to seawater. Beyond the ocean, you’ll find it in power generation facilities, particularly in condenser boxes and other critical systems handling cooling water. Its reliability ensures the safety and longevity of structures where failure is simply not an option.
