Nestled in the industrial heart of Amman, Jordan, Nizar Sheetsandplates has built a reputation for supplying robust and reliable steel solutions. We take pride in introducing our C50 High Carbon Steel Sheet and Plates, a material crafted for those demanding exceptional strength and durability. This high-grade steel is the cornerstone for projects where failure is not an option, and it reflects our commitment to providing Jordanian industries with the high-performance materials needed to build and innovate with unwavering confidence.
The strength of C50 steel begins with its precise composition, carefully balanced with a higher carbon content to achieve its notable properties. This formulation gives the material excellent tensile strength and a remarkable resistance to wear, making it significantly harder and more durable than milder steels. While this inherent hardness means it is less malleable, it is precisely this characteristic that makes C50 ideal for applications where the material must withstand immense pressure and continuous abrasion without degrading.
| Thickness Range | 0.10 – 5.00 MM |
| Width Range | 5.00 – 1250 MM |
| Form | Can be supplied in Coil or Sheet form |
| Sheet Length (CTL) | 300 – 3000 MM |
| Edge | Mill edge or Sheared edge |
| Coil / Sheet Pallet Weight | Weight of each Coil or Sheet pallet can be customized as per customer’s need |
| Coil ID / OD | ID or OD of each Coil can be customized as per customer’s need |
| Packing | High-end export packing for sea or road travel, completely safe during transit. Duly oiled with anti-rust oil, wrapped in hessian cloth & high-density plastic sheets to prevent moisture. Further strapped with high tensile strips. For identification & tracing, non-erasable polyester stickers are placed on each material |
| Delivery Time | Dispatched within 10 days to 2 months, depends upon the required size |
| Some Applications | Auto components such as Washers, Clutch components, various types of Springs, Pen Clips, Hanger Clips, Cycle/Motor Chains, etc. |
Element |
C |
Si |
Mn |
P |
S |
Cr |
Cu |
Ni |
Content (%) |
0.47 – 0.55 |
0.17 – 0.37 |
0.50 – 0.80 |
0.03 |
0.03 |
0.15 |
0.25 |
0.30 |
GRADE |
Tensile Strength min |
Yield Strength min |
Elongation min. |
contraction min |
impact min |
Hardness Max |
|
σb/M Pa |
σs/M Pa |
δ5/% |
ψ/% |
Akv/J |
Without heating |
annealing |
|
C50 |
630 |
375 |
14 |
40 |
31 |
241 |
207 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
C50 High Carbon Steel Plates offer numerous advantages, including superior strength and hardness, making them ideal for heavy-duty industrial applications. Their high tensile and yield strength ensure excellent load-bearing capacity, while their wear resistance provides durability in demanding environments. C50 plates also offer good machinability, allowing for easy fabrication and customization for specific applications. The steel’s exceptional toughness and ability to withstand high-stress conditions make it perfect for use in components like gears, shafts, and machinery. Additionally, C50 High Carbon Steel Plates are cost-effective, providing long-lasting performance and reliability.
Yes, we offer custom sizes for C50 High Carbon Steel Sheet and Plates to meet specific project needs. Our team at Nizar Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| SAE / AISI – American | SAE 1050 |
| DIN – Germany | C50 / CK50 |
| EN – English / BS – British | – |
| JIS – Japanese | S50C |
| UNI – Italy | C50 |
This exceptional durability makes C50 steel indispensable for a range of heavy-duty applications. You will find it forming the backbone of industrial machinery, worn-resistant components like gears and shafts, and robust cutting tools that require a sharp, long-lasting edge. Its reliability also extends to the construction of high-strength frames, agricultural implements that tackle tough terrain, and essential parts in the automotive and mining sectors. Essentially, wherever there is a need for a material that can endure relentless use, C50 sheets and plates provide a trusted and resilient solution.
