Aluminium 5005 Plates and Sheets are top-notch, corrosion-resistant aluminium products crafted and provided by Nizar Sheetsandplates in Amman, Jordan. Renowned for their impressive workability, smooth surface finish, and decent strength, these 5005 alloy sheets and plates find their way into various architectural, marine, and general fabrication projects. This alloy shines when it comes to anodizing, making it perfect for both decorative and protective finishes. With great weldability and formability, Aluminium 5005 Plates and Sheets are a go-to choice for structures, whether indoors or outdoors. Industries trust this alloy for its durability, appealing look, and long-lasting performance in mildly corrosive settings.
Aluminium 5005 alloy is primarily made of aluminium, with a small addition of 0.8% magnesium, along with trace amounts of silicon, iron, copper, manganese, chromium, and zinc. This combination gives the alloy moderate tensile strength, outstanding corrosion resistance, and excellent anodizing capabilities. It also boasts good weldability and formability, making it a fantastic option for fabrication tasks. Aluminium 5005 holds its own during bending, cutting, and machining, all while keeping its surface quality intact. Its mechanical properties make it a reliable choice for structural, architectural, and marine applications that demand strength, durability, and a polished finish.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Chemical Properties | % Value |
| Silicon (Si) | 0.30 |
| Chromium (Cr) | 0.10 |
| Manganese (Mn) | 0.20 |
| Magnesium (Mg) | 0.5-1.1 |
| Copper (Cu) | 0.20 |
| Titanium (Ti) | – |
| Iron (Fe) | 0.7 |
| Zinc (Zn) | 0.25 |
| Aluminium (Al) | Balance |
| Property | Value |
| Proof Stress | 120 Min MPa |
| Tensile Strength | 145 – 185 MPa |
| Elongation at 50 mm | 3 Min % |
| Hardness Brinell | 47 HB |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aluminium 5005 Sheets and Plates offer numerous advantages, including excellent corrosion resistance, making them suitable for marine and outdoor environments. They have superior anodizing qualities, ensuring an attractive, durable finish ideal for architectural applications. Their lightweight nature allows for easy handling and fabrication, reducing transportation and installation costs. Aluminium 5005 demonstrates good weldability and moderate strength, providing versatility across various industries. Its non-heat-treatable but cold-workable property enhances strength when needed, making it a reliable choice for roofing, cladding, signage, and decorative applications where durability and aesthetics are key.
Yes, we offer custom sizes for Aluminium 5005 Plates and Sheets to meet specific project needs. Our team at Nizar Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| Standard | UNS | ISO | BS | DIN |
| 5005 | A95005 | AlMg1 | N41 | 3.3315 |
| Properties | Metric | Imperial |
| Tensile strength | 130 MPa | 18855 psi |
| Yield strength | 125 MPa | 18130 psi |
| Shear strength | 83 MPa | 12039 psi |
| Fatigue strength | 55 MPa | 7977 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 10% | 10% |
| Hardness | 35 | 35 |
Aluminium 5005 Plates and Sheets are commonly found in architectural panels, roofing, facades, curtain walls, signboards, and decorative projects, thanks to their superb anodizing features. They also play a vital role in marine components, as this alloy stands up to corrosion in seawater. The fabrication industry utilizes 5005 sheets for storage tanks, vehicle panels, appliances, electrical enclosures, cookware, and furniture, all due to their formability and sleek finish. In transportation, they’re used for interior panels and trims, providing lightweight yet durable solutions.
