Nizar Sheetsandplates, based in Amman, Jordan, is a trusted manufacturer and supplier of top-notch alloy steel products designed for high-temperature and pressure vessel applications. They specialize in Alloy Steel Grade 22 Sheets and Plates, which are highly sought after in industries that demand exceptional strength, creep resistance, and thermal stability. Adhering to the relevant ASTM/ASME standards, these sheets and plates are crafted with meticulous quality control and precise dimensional accuracy. Nizar Sheetsandplates guarantees reliable performance and consistent material quality for critical industrial environments.
Alloy Steel Grade 22 is a chromium-molybdenum alloy steel that contains around 2.0–2.5% chromium and 0.9–1.1% molybdenum. This unique blend gives it impressive tensile and yield strength, outstanding creep resistance, and good oxidation resistance at high temperatures. The material also boasts good toughness, a stable microstructure, and dependable weldability when the right procedures are followed. Typically, Grade 22 sheets and plates are provided in either a normalized or quenched and tempered state, depending on the specific application needs.
Alloy Steel Sheets and Plates Specification : ASTM A387 / ASME SA387
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
| BS | EN | ASTM/ASME | UNS | DIN |
|---|---|---|---|---|
| 621B | – | A387 / SA 387 | K11757 | – |
| C | Mn | P | S | Si | Cr | Mo |
|---|---|---|---|---|---|---|
| 0.04 – 0.15 | 0.25 – 0.66 | 0.035 | 0.035 | 0.5 max | 1.88 – 2.62 | 0.85 – 1.15 |
| A387 / SA387 Grade 22 | Class 1 | Class 2 |
|---|---|---|
| Tensile Strength (ksi) | 60-85 | 75-100 |
| Tensile Strength (MPa) | 415-585 | 515-690 |
| Yield Strength (ksi) | 30 | 45 |
| Yield Strength (MPa) | 205 | 310 |
| Elongation in 200mm (%) | – | – |
| Elongation in 50mm (%) | 18 | 18 |
| Reduction of area in % | 45 | 45 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nizar Sheets and Plates based in Amman, Jordan, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Alloy Steel Gr 22 Sheets and Plates offer numerous advantages, including excellent resistance to high temperatures, oxidation, and corrosion, making them ideal for harsh environments. Their superior tensile and yield strength ensure durability under heavy loads and pressure. Enhanced creep resistance and toughness allow them to withstand prolonged thermal and mechanical stress, extending their service life in demanding applications. These plates are also versatile, with easy machinability and weldability, facilitating efficient fabrication. Commonly used in power plants, boilers, and pressure vessels, they ensure reliability, safety, and cost-effective performance.
Yes, we offer custom sizes for Alloy Steel Gr 22 Sheets and Plates to meet specific project needs. Our team at Nizar Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Alloy Steel Grade 22 sheets and plates find extensive use in equipment that operates under high temperatures and pressure. Common applications include pressure vessels, boilers, heat exchangers, reactors, separators, and piping components in refineries, petrochemical plants, and power generation facilities. They are also utilized in steam drums, superheaters, and process equipment that handle hot gases and fluids. Thanks to their remarkable creep strength, thermal stability, and durability, Grade 22 plates are the go-to choice for critical industrial applications that require a long service life, safety, and dependable performance.
