Located in the heart of Amman, Jordan, Nizar Sheetsandplates has built a strong reputation for supplying high-performance materials to demanding industries. We are proud to offer Alloy C263 Foil, a premium nickel-cobalt alloy engineered for situations where exceptional strength and heat resistance are non-negotiable. This product line reflects our commitment to providing local and regional engineers and manufacturers with access to world-class materials that enable innovation and ensure reliability in the most challenging applications, right from our base in the Middle East.
The exceptional performance of Alloy C263 Foil comes from its sophisticated composition, primarily nickel and cobalt, with significant additions of chromium and molybdenum. This specific blend gives the foil its remarkable ability to retain tremendous strength and resist oxidation at temperatures that would cause most other metals to fail. It’s this powerful combination of high tensile strength and outstanding thermal stability that makes it a go-to material for critical components operating under extreme stress and heat.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Properties | Metric | Imperial |
|---|---|---|
| Density | 8.359 g/cm3 | 0.302 lb/in3 |
| Melting point | 1300-1335°C | 2372-2471°F |
Alloy C263 foil provides excellent advantages for high temperature applications. It provides outstanding resistance to oxidation and creep, making it ideal for aerospace and industrial applications. The high weldability and formability of the alloy ensures easy fabrication in complex shapes. Its excellent thermal stability and resistance to cracking under thermal cycling enhances reliability in extreme conditions. Additionally, alloy C263 exhibits corrosion and oxidation resistance up to 980°C (1800°F), providing long durability. Its combination of strength, ductility and thermal performance makes it desirable in gas turbines and heat treatment equipment.
You will typically find this high-strength foil at work in the hottest sections of jet engines and gas turbines, where it’s formed into vital components like combustion liners and flame holders. Its reliability also makes it indispensable in the aerospace sector for various exhaust and thrust reverser systems. Beyond flight, this material is crucial in power generation equipment and any high-temperature industrial process, proving its worth wherever performance cannot be compromised.
